10-0487 Series

This recessed seat cover and toilet paper dispenser with sanitary napkin disposal for toilet compartments is specially manufactured to meet new Building Code requirements
for ADA accessibility when mounted properly. Sleek and durable type 304 stainless steel, and double toilet tissue dispensers with vandal resistant rollers makes this accessory ideal for all building types and traffic environments.

Includes stainless steel collar for surface mounting.

DURABILITY:
• Service door attached with full-length 3/16" multi-staked piano hinge
• Panels and Doors: 18 gauge type 304 stainless steel
• Face frame and cabinet; 22 gauge type 304 stainless steel

CAPACITY:
• Holds and dispenses 500 paper seat covers
• Holds and dispenses two standard toilet paper rolls
• Removable waste container shall have a capacity of 0.45 gal (1.7 L)

Recessed Model:

28″ x 14-¼″ x 4-¼″

(711 x 362 x 108 mm)

Wall Opening:

26-½″ x 12-⅞″ x 4-¼″

(673 x 327 x 108)

Surface Mounted Model:

28″ x 14-¼″ x 4-¹⁵⁄₃₂″

(711 x 362 x 114 mm)

Download: 10-0487-L

Download: 10-0487-R

Download: 10-0487-L-9

Download: 10-0487-R-9
